500 CC LIQUID-COOLED REVOLUTION X™ ENGINE: The blacked-out, liquid-cooled V-Twin engine is built to conquer the hot and heavy traffic of urban streets. You can count on smooth response to the progressive throttle when you want to get through any hole that opens up in front of you.
OPTIONAL ANTI-LOCK BRAKES (ABS): The sophisticated, factory-installed ABS gives you confidence in the saddle knowing your bike’s going to behave when you need it.
LIGHT LIFT OFF FORCE: Lifting it up off the side stand is easy, thanks to its low weight and low center of gravity. It makes pulling out from the curb feel as effortless as putting your thumb to the starter button.
LOW SEAT HEIGHT: The seat height is just 28-inches. And the frame and seat are narrow, which makes for an even easier reach. The advantages of a low seat also shine when the light turns green. It gives you a low center of gravity for confidence when you’re negotiating traffic, just rolling slow through a parking lot looking for a spot.
SPECIALLY TUNED SHOCKS: Specifically tuned and dialed in for the weight of the bike, the geometry of the frame, and the position of the rider. You’ll experience a smooth ride and excellent handling when you encounter rough urban pavement.
DARK, AGGRESSIVE, CUSTOM LOOK: Sports an all-black two-toned exhaust, black cast aluminum wheels, blacked-out front end with café inspired speed screen, and a chrome medallion made of steel on the fuel tank.
Brakes: Front and Rear – 2-piston floated, Wheels: Front and Rear – 7-spoke Cast Aluminum, Wheel Colors: Black: Tires: Front – 100/80-17, Rear – 140/75 R15, Length: 87.2 in, Weight: As Shipped – 492 lb, In Running Order – 514 lb, Ground Clearance: 5.7 in, Wheelbase: 59.8 in, Seat Height: Laden – 25.7 in, Unladen – 28.3 in, Lighting: High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning: Engine: Revolution X™ V-Twin, Cooling: Liquid, Displacement: 494 cc (30 cu. in.), Bore x Stroke: 2.72 x 2.6 in, Torque: 29.5 ft. / lb. @ 3,500 rpm, Gear Ratio: Overall: 1st – 14.272, 2nd – 10.074, 3rd – 7.446, 4th – 6.006, 5th – 5.037, 6th – 4.533
Fuel System: Mikuni Single Port Fuel Injection, 35 mm bore
Exhaust: Black Two-into-one, Fuel Capacity: 3.5 gal, MPG Rating: Combined City / Hwy – 64.4 mpg, OPERATIONAL: Rake: Steering head – 32 deg, Trail: 4.5in.
Additional Colors: Vivid Black, Olive Gold, Electric Blue, Bonneville Salt Pearl, Vivid Black Deluxe, Wicked Red Deluxe, Bonneville Salt Pearl Deluxe
