MILWAUKEE-EIGHT® 117 TWIN-COOLED™ ENGINE: The most powerful Twin-Cooled V-Twin engine ever offered from the H-D® factory, and only available in CVO™ models. Features color accented Rocker Box Lowers with Blaze Red finish.
H-D™ CONNECT SERVICE: With subscription-based cellular connectivity, you can connect to your bike through your smart phone using the latest version of the Harley-Davidson™ App. Check your bike’s vitals including fuel level, get tamper alerts and stolen-vehicle tracking, and more.
REFLEX™ DEFENSIVE RIDER SYSTEMS: A new standard package, Reflex™ Defensive Rider Systems is a collection of technology designed to match motorcycle performance to available traction during acceleration, deceleration and braking.
PREMIUM PAINTS AND FINISHES: Exclusive paint colors and designs executed to a level of intricate quality that is unmatched in the motorcycle and automotive categories.
INFOTAINMENT SYSTEM: An evolved interface experience that offers a contemporary look, feel and function, with exceptional durability and features designed specifically for motorcycling. Every element is optimized to enhance the rider’s interaction with the bike and connectivity with the world.
HIGH-PERFORMANCE TOURING SUSPENSION: Dual bending valve front suspension and emulsion rear suspension with hand-adjustable pre-load put you in control of a plush ride.
LED LIGHTING: The lighting is all LED: headlamp, fog lamps, tail and brake lamps and signals. See and be seen with these darkness-defying lights.
TOMAHAWK™ CONTRAST CUT WHEELS: Features a Front 19-inch and new Rear 18-inch wheel with custom style-matched hubcap.
PREMIUM HEATED SEATS: The rider and passenger seat covers are heated for riding comfortably, and longer, in cooler weather.
CUSTOM TOURING STYLE: Full-on custom treatment from fender to fender. You get custom seat covers and stitching, a heavy breather air cleaner with two paint treatments, billet fairing mount mirrors—the list goes on.
WIRELESS HEADSET: The Boom!™ Audio 30K Bluetooth® headset lets you call hands-free on your Bluetooth® mobile phone, listen to stereo music or voice instructions of GPS navigation and have intercom conversations with your passenger or fellow riders.
Brakes: Front – 32 mm 4 piston fixed, Rear – Floating 36 mm piston integrated park brake, Wheels: Front / Rear – Gloss Black and Contrast Clear Tomahawk, Optional Style – Charcoal Grey with Contrast Satin Tomahawk, Tires: Front – 130 / 60B19 M / C 61H, Rear – P215 / 45R18 83T
Length: 105.1 in. (2,670 mm), Weight: As Shipped – 1,239 lb. (563 kg), In Running Order – 1,269 lb. (577 kg)
Ground Clearance: 5.1 in. (130 mm), Wheelbase: 65.7 in. (1,670 mm), Seat Height: Laden – 25.9 in. (658 mm), Unladen – 28.1 in. (715 mm), Primary Drive: Chain, 34 / 46 ratio
Instrumentation: Speedometer, tachometer, fuel, and voltage gauges; display features odometer, trip A, trip B, range to empty, gear indicator, and tire pressure
Lighting: High Beam, running lights, battery, neutral, low oil pressure, engine diagnostics, cruise control, low fuel warning, reverse, park brake, fog/aux lamp indicator, traction control, security/fault indication, coolant temp, turn signal, ABS, TPMS
Infotainment System: Type – Full Color TFT, Watts Per Channel – 75, Speakers – 4, Speaker Size – Boom! Audio Stage I, Headset Specifications (if equipped) – Boom! Audio 30K Wireless Headset, AM/FM – Standard, Weather Band (WB) – Standard, SD Card, Flash Drive and MP3 – via USB Connection – Supported, SiriusXM Presets – 20 – P&A Upgrade (USA & Canada only), Hands-free Mobile Phone – via Bluetooth – Standard, Voice Recognition Languages: Phone Functions, Tuner/Media/Navigation and Text-to-Speech (TTS)
Rider/Passenger Intercom – Standard, Vehicle Information Screen (Air temperature, oil pressure and EITMS) – Standard, USB – USB/MTP/iPod/iPhone, Bluetooth – Phone/Media Supported, Engine: Twin-Cooled™ Milwaukee-Eight® 117, Displacement: 1,923 cc (117 cu. in.), Bore x Stroke: 4.075 x 4.5 in. (104 x 114 mm), Torque: 125 ft. lb. (170 Nm) @ 3,750 rpm, Compression Ratio: 10.2:1, Gear Ratio: Overall: 1st – 10.534, 2nd – 7.302, 3rd – 5.423, 4th – 4.392, 5th – 3.741, 6th – 3.157, Fuel System: Electronic Sequential Port Fuel Injection (ESPFI), Exhaust: Chrome, 2-1-2 dual exhaust with slash cut mufflers, Fuel Capacity: 6 gal. (22.7 l): Oil Capacity: 5 qt. (4.7 l), MPG Rating: Estimated City / Hwy – 40 mpg (5.9 l / 100 km), OPERATIONAL: Rake: 26°, Trail: 3.94 in. (100 mm)
Additional Colors: Blizzard White Pearl With Lightning Silver / Stormcloud, Black Stardust With Magnetic Gray / Wicked Red
Includes: Security System – Standard, Cruise Control – Standard, Premium Radio Option – Standard, Cargo Capacity: Luggage – 6.8 cu. ft. (0.19 m3)
